PCB ASSEMBLY SERVICES



Here at Nano ES we work with a number of dedicated partners. NanoES is able to support a wide range of assembly requirements. We will identify the right partner for you to ensure your products are manufactured right and on time.

​

Offering everything from rapid prototyping, PCB assembly through to test and box build.

​

We aim to respond quickly and attempt to get most quotes back within 48 hours to ensure you have the information you need in a timely manner to make a decision.

Rapid Prototyping

FACTORY 1, 2 & 3

With access to 10 SMT lines across our network, we are able to quickly respond to customer's requirements. In-house X-ray is available to support those tricky BGA & DFN packages.

​

A number of our factories specialise in lower volume builds.

​

Hand Assembly capability for customers looking for 1 off builds or small volumes for development. Avoiding the cost of setting up a production line.

Prototyping to Medium Batch Size

FACTORY 4 & 5

3 SMT lines allows for a range of volumes to be supported, from prototyping to medium volume requirements.

​

Solder Jet Printing

​

Vapour Phase Reflow

​

Box build capability

​

Conformal coating and semi automatic potting capabilities

​

In-house design and layout support.

Small, Medium & High Volume Manufacturing

FACTORY 6, 7 & 8

6 SMT lines and the ability to use manufacturing in Europe and Asia to support low cost or high volume assembly.

​

3D AOI and In-house X-Ray

​

Box Build capability and capacity for logistics support.


Computer Circuit Board Macro

FACTORY 1 & 2  - KEY EQUIPMENT

Soundboard Repair

FACTORY 3 & 4 - KEY EQUIPMENT

Computer Circuit Board

FACTORY 5, 6 & 7 - KEY EQUIPMENT

Rapid prototyping.
MyData & Europlacer SMT for reduced wastage on small builds
Hand Assembly for 1 off or small volume prototypes
Cable Assembly & Wiring Looms
AOI and In House X Ray
IPC-A-610  Level 3 Certified
JSTD Certified
ISO 9001:2015

  • Samsung CP45NEO SMT Machines

  • MY500 Jet Printer

  • VP450 Vapour Phase

  • 0201 and 0.3mm Capability

  • Test & Box Build Capability

  • Mirtec 3D Omni AOI

  • In House X-Ray

  • Conformal Coating

  • Semi Auto Potting

  • In House Design Support

  • IPC-A-610 Level 3 Certified

  • ISO 9001:2015

  • Yamaha,  Mirae & MyData SMT machines

  • PTH Auto Insertion

  • 01005 and 0.4 x 0.2mm component capability

  • LED based PCB assembly specialisation

  • 3D AOI and In House X Ray

  • Test & Box Build Capability

  • EMC Pre-compliance testing

  • UK and Offshore Manufacturing

  • Automotive Expertise & PPAP Capability

  • IPC-A-610 Level 3 Certified

  • ISO 9001:2015
